2025 Stoltzfus BMS1516

Description

Max Load / Capacity 15 tons Hopper Volume 225 cu ft Hopper Length 16 ft Hopper Width 74 in Hopper Depth 37 in Overall Length 24 ft Overall Width 94 in Overall Height 78 in Wheel Track (center) 80 in Tires (standard) 21.5L × 16.1, 14-ply Weight (empty) 5,700 lbs Walking beam suspension (heavy duty) for handling loads and reducing stress on axle components Top-driven hydraulic spinners (spinner drive motors mounted above the flow of material) PTO or hydraulic body chain drive (depending on configuration) Unibody, fully welded design (hopper & body are one integrated weldment) 30″ slat-style conveyor chain 53° hopper side walls (to promote material flow and reduce bridging) 4″ vertical drop pan (to reduce bridging) Telescoping chain tensioners, self-aligning idler shafts, structural reinforcements, extra body bracing Optional features: fertilizer kit (low-rate spreading down to ~200 lb/acre), VRT (variable rate technology) compatibility, tarps, flotation tires, tarping systems, shredders/agitating mechanisms, lighting, etc.
