KBH TT3000SF

Description

KBH Side Discharge 3 Compartment Model# TT3000SF KBH 3 HOPPER SIDE DISCHARGE DRY FERTILIZER TENDER Hoppers Lower Center of Gravity Three 300 Cubic Foot Hoppers Each hopper can be split if needed. 900 Cubic Foot Capacity Stainless Steel Hopper Cradle (Bolted) Stainless Steel Hopper Safety/Agitation Ports Hydraulic Hopper Vibrators SRT Spring Assist Roll Tarp Dump In Height 10'5" (Not Including Tarp Bows/End Caps) Augers Stainless Steel Augers & Shafts Stainless Steel Split Auger Motor Couplers (Bolt Together) Discharge Auger Hanger Bearing: Bronze Bushing Discharge Auger Lower Bearing: Stainless Steel Remote Grease Zerk Station Hydraulic Poly Clean Out Doors Unload Rate 2-3 Tons Per Minute Max Unload Height: 14'7" (10'2" Reach From Fender)** We order our stocking trailers with 3' longer augers- 17' unload height!! Min Unload Height: 9'2" (13'2" Reach From Fender) Trailer Polyurethane Enamel Paint With Epoxy Primer Cast Iron Axle Hangers Length: 32' Long Empty Weight: 16,340 lbs. Stainless Steel Front & Rear Fenders 255-70R/22.5 Radial Tires Stainless Steel Axle/Air Tank & Engine cover Isuzu Liquid cooled diesel engine- self-contained trailer
