Bobcat E35

Description

A popular choice in the 3-ton size class, the Bobcat® E35 compact excavator (mini excavator) excels on space-constrained jobsites, such as next to buildings or other obstacles. The Zero Tail Swing (ZTS) provides unrestricted rotation, greater flexibility and reduced potential for damage to the machine and surrounding property. The Tier 4-compliant E35 is available with an angle blade option, long arm option or clamp-ready extendable arm option. Engine Specifications Emissions Tier (EPA): Tier 4 Engine Fuel: Diesel Maximum Governed RPM: 2,400 rpm Horsepower: 33.5 hp (25 kW) Turbocharged Engine: Optional Performance Specifications Operating Weight: 7,468 lb. (3387 kg) Weight Class: 3.4 t Travel Speed - High: 2.9 mph (4.7 km/h) Travel Speed - Low: 1.6 mph (2.6 km/h) Arm Digging Force: 4,589 lb.f (20,413 N) Bucket Digging Force: 6,968 lb.f (30,995 N) Rated Lift Capacity: 2866 lb. (1300 kg) Lift Radius: 118 in. (2997 mm) Boom Swing - Left: 75 deg. Boom Swing - Right: 55 deg. Maximum Dig Depth: 10.2 ft. (3.1 m) Max Dump Height: 11 ft. (3.4 m) Maximum Reach at Ground Level: 17.2 ft. (5.2 m) Capacities Fuel Tank: 14 gal. (53 L) Hydraulic System Specifications Auxiliary Std Flow: 16.9 gal./min (64 l/min) Auxiliary Pressure: 2,987 psi (205.95 bar) Dimensions Length: 189.7 in. (4818 mm) Overall Length in Travel Position: 189.7 in. (4818 mm) Width: 69 in. (1753 mm) Height: 95.6 in. (2428 mm) Height with Operator Cab: 95.6 in. (2428 mm) Features Air Conditioning: Optional Cab Enclosure: O
