Make
John Deere
Model
1023E
Category
Tractors
Subcategory
Less than 40 HP
Stock No.
9724a88e3b374d99074d1db151d40257
City
Cresson
State
PA
Condition
Used
Horsepower
23 HP
Rear PTO
Yes
Meet the most capable sub-compact tractors on the market: the John Deere 1 Family. With up to 25 available horsepower, AutoConnect™ decks, iMatch™ compatibility, not to mention hundreds of implement and attachment options… even the hardest chore on your list doesn’t stand a chance. Features Powerful Final Tier 4-compliant diesel engine New, easy-lift hood with dual gas-charged lift struts Auto-Connect™ mid-mower deck can be installed or removed in less than 5 minutes Easy-to-operate two speed hydrostatic transmission Engine Family: EYDXL0.99NS2 FYDXL0.99NS2 GYDXL0.99NS2 Manufacturer: Yanmar Engine model: 3TNM74F-NCJT Engine power (gross): 16.5 kW/22.4 hp Power take-off (PTO) power: 10.8 kW/14.5 hp Rated engine speed: 3200 rpm Type: Diesel Injection pump type: Indirect Injection Aspiration: Natural Emissions compliance: Final Tier 4 Cylinders/displacement: 3 / 0.993 L3 / 60.6 cu in. Number of cylinders: Three Cylinder liners: Cast-In-Block Bore and stroke: 74x77 mm/2.91 x 3.03 in. Compression ratio: 23.5:1 Lubrication: Pressurized Cooling system: Water pump Air cleaner: Dual element Engine torque at rated speed: 49.2 Nm/36.3 lb-ft Fuel tank capacity: 21.2 L/5.6 U.S. gal. Electrical Battery size: 500 CCA Alternator (12-V): 40 amp Starter size: 1.2 kW/1.6 hp Fuel System Type: Indirect Injection Fuel consumption: 5.3 L/hr/1.4 U.S. gal./hr Transmission Standard transmission; forward/reverse: Hydrostatic - 2 range Left-hand reverser: No Final drive: Bull Gear Brakes: Wet disc (left
